| Category |
KOMATSU Spare Parts |
| Name |
Steering Valve |
| Parts No |
195-40-00801 195-40-00800 |
| Machine Number |
D375A-3 D375A-3A D375A-3D |
| Lead time |
1-3 DAYS |
| Quality |
Brand new, OEM quality |
| MOQ |
1 PCS |
| Means of transport |
By sea/air, DHL FEDEX UPS TNT |
| Packing |
As request or standard packing |
- Key functions & working principle
| Working Principle |
1. When the operator turns the steering wheel, mechanical force is transmitted to the valve’s spool via a linkage/rotary shaft, shifting the spool from its neutral position |
| 2. The shifted spool opens oil passages, directing pressurized hydraulic oil from the machine’s main hydraulic pump to one side of the steering cylinder (e.g., left cylinder for left turn) |
| 3. Oil is simultaneously routed from the opposite side of the steering cylinder back to the hydraulic tank (return line), allowing the cylinder to extend/retract |
| 4. The pressure-compensated design modulates oil flow rate to match steering wheel speed, ensuring smooth, proportional movement of the front axle/wheels |
| 5. When the steering wheel is centered, the spool returns to neutral, closing oil passages and locking the steering cylinder(s) in position to maintain straight travel |
| Core Functions |
1. Precise Steering Control: Converts operator input into accurate hydraulic oil flow, enabling smooth left/right turns and straight-line stability for wheel loaders/graders |
| 2. Load Compensation: Maintains consistent steering response regardless of engine speed or hydraulic system load (e.g., lifting heavy loads while steering) |
| 3. Overload Protection: Integrated relief valve prevents damage to steering cylinders/linkages from excessive pressure |
| 4. Safety: Emergency manual override (where fitted) ensures basic steering control if hydraulic power is lost |
| 5. Efficiency: Minimal internal leakage reduces hydraulic energy loss, lowering fuel consumption and heat generation |
BULLDOZERS D375A-3 D375A-3A D375A-3D Komatsu
- More other steering valve applied to KOMATSU heavey machine
| 195-40-00800 STEERING VALVE ASS'Y |
| D375A |
| |
| 195-40-00901 STEERING VALVE ASS'Y,(B) |
| D375A |
| |
| 195-40-00900 STEERING VALVE ASS'Y,(B) |
| D375A |
| |
| 195-22-00120 STEERING ASS'Y,(B) |
| D375A |
| |
| 07442-71102 STEERING PUMP ASS'Y |
| D355A, D355C |
| |
| 195-22-00014 STEERING CLUTCH A. |
| D355A, D355C |
| |
| 2691-6-11100 STEERING VALVE ASS'Y |
| JV32W |
| |
| 113-22-00011 STEERING CLUTCH A. |
| D31A, D31P, D31PL, D31Q, D31S |
| |
| 120-22-00020 STEERING CLUTCH A. |
| D30AM, D31A, D31E, D31P, D31PL, D31Q, D31S |
| |
| 17M-22-42005 STEERING VALVE ASS'Y |
| D275AX |
| |
| 120-22-00011 STEERING CLUTCH A. |
| D40A, D40AM, D40F, D40P, D40PF, D40PL, D40PLL, D41A, D41E, D41P, D41Q, D41S |
| |
| 124-40-00010 STEERING VALVE ASS'Y |
| D40A, D40AF, D40PF, D40PL, D40PLF, D45A, D45P, D50A, D50P, D50PL, D53A, D53P |
| |
| 195-22-00120 STEERING ASS'Y,(B) |
| D375A |
| |
| 195-22-71001 STEERING ASS'Y |
| D375A |
| |
| 195-22-71000 STEERING ASS'Y |
| D375A |
| |
| 195-40-00900 STEERING VALVE ASS'Y,(B) |
| D375A |
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| |
195-40-00801 |
[1] |
STEERING VALVE ASS'Y Komatsu |
35.1 kg. |
| |
|
|
["SN: 17261-UP"] analogs:["1954000800"] |$11. |
|
| |
195-40-00800 |
[1] |
STEERING VALVE ASS'Y Komatsu |
35.1 kg. |
| |
|
|
["SN: 17001-17260"] analogs:["1954000801"] |$12. |
|
| |
195-40-00901 |
[1] |
STEERING VALVE ASS'Y,(B) Komatsu |
28.11 kg. |
| |
|
|
["SN: 17261-UP"] |$13. |
|
| |
195-40-00900 |
[1] |
STEERING VALVE ASS'Y,(B) Komatsu |
24.54 kg. |
| |
|
|
["SN: 17001-17260"] |$14. |
|
| 1. |
14X-40-11112 |
[1] |
BODY Komatsu |
12 kg. |
| |
|
|
["SN: 17743-UP"] analogs:["14X4011111"] |
|
| 1. |
14X-40-11111 |
[1] |
BODY Komatsu |
12 kg. |
| |
|
|
["SN: 17001-17742"] |
|
| 2. |
07043-70108 |
[4] |
PLUG Komatsu |
0.005 kg. |
| |
|
|
["SN: 17001-UP"] analogs:["07043A0108"] |
|
| 3. |
14X-40-11650 |
[1] |
BODY Komatsu |
0.08 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 4. |
14X-40-11660 |
[1] |
VALVE Komatsu |
0.04 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 5. |
14X-40-11670 |
[1] |
VALVE Komatsu |
0.045 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 6. |
07750-01628 |
[1] |
SPRING Komatsu |
0.002 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 7. |
07002-22434 |
[1] |
O-RING Komatsu |
1.1 kg. |
| |
|
|
["SN: 17001-UP"] analogs:["0700232434", "R0700222434"] |
|
| 7. |
07002-52434 |
[1] |
O-RING,(B) Komatsu China |
0.02 kg. |
| |
|
|
["SN: 17001-UP"] analogs:["0700242434", "0700052434"] |
|
| 8. |
17A-40-11252 |
[2] |
PLUG Komatsu |
0.17 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 10. |
195-40-43231 |
[2] |
SPRING Komatsu |
0.013 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 11. |
19M-40-11160 |
[2] |
PISTON Komatsu |
0.02 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 12. |
195-40-43211 |
[2] |
VALVE Komatsu China |
|
| |
|
|
["SN: 17001-UP"] |
|
| 13. |
14Z-40-11340 |
[2] |
GUIDE Komatsu |
0.02 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 14. |
195-40-43241 |
[2] |
SPRING Komatsu |
0.01 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 15. |
175-15-56470 |
[8] |
SHIM, 0.50MM Komatsu |
0.001 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 16. |
14X-40-11221 |
[2] |
BOLT Komatsu |
0.035 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 17. |
195-40-43221 |
[2] |
GUIDE Komatsu China |
|
| |
|
|
["SN: 17001-UP"] |
|
| 18. |
195-40-43251 |
[2] |
CYLINDER Komatsu China |
|
| |
|
|
["SN: 17001-UP"] |
|
| 19. |
14X-40-11261 |
[2] |
NUT Komatsu |
0.095 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 20. |
14X-40-11272 |
[2] |
NUT Komatsu China |
|
| |
|
|
["SN: 17001-UP"] |
|
| 21. |
195-40-43162 |
[2] |
PLUG Komatsu China |
|
| |
|
|
["SN: 17261-UP"] analogs:["1954043161"] |
|
| 21. |
195-40-43161 |
[2] |
PLUG Komatsu China |
|
| |
|
|
["SN: 17001-17260"] analogs:["1954043162"] |
|
| 23. |
195-40-43131 |
[2] |
SPRING Komatsu |
0.02 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 24. |
195-40-31540 |
[2] |
PISTON Komatsu |
0.02 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 25. |
195-40-43111 |
[2] |
VALVE Komatsu |
0.1 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 27. |
195-40-43142 |
[2] |
SPRING Komatsu |
0.01 kg. |
| |
|
|
["SN: 17261-UP"] |
|
| 27. |
195-40-43141 |
[2] |
SPRING Komatsu China |
|
| |
|
|
["SN: 17001-17260"] |
|
| 30. |
195-40-43121 |
[2] |
GUIDE Komatsu China |
|
| |
|
|
["SN: 17001-UP"] |
|
| 31. |
195-40-43151 |
[2] |
CYLINDER Komatsu China |
|
| |
|
|
["SN: 17001-UP"] |
|
| 33. |
14X-40-11373 |
[2] |
NUT Komatsu China |
|
| |
|
|
["SN: 17001-UP"] |
|
| 34. |
424-15-16420 |
[8] |
SHIM, 0.5MM Komatsu |
0.011 kg. |
| |
|
|
["SN: 17261-UP"] |
|
| 35. |
14X-40-11411 |
[1] |
COVER Komatsu China |
|
| |
|
|
["SN: 17001-UP"] |
|
| 36. |
14X-40-11421 |
[1] |
GASKET Komatsu |
0.002 kg. |
| |
|
|
["SN: 17001-UP"] |
|
| 37. |
01010-81025 |
[2] |
BOLT Komatsu |
0.36 kg. |
| |
|
|
["SN: 17001-UP"] analogs:["0101051025", "0101651025", "801015109"] |
|
| 38. |
01643-31032 |
[2] |
WASHER Komatsu |
0.054 kg. |
| |
|
|
["SN: 17001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] |
|
- We could supply the following spare parts
1 Hydraulic parts: hydraulic pump, main valve, hydraulic cylinder, final drive, travel motor, swing machinery, swing motor etc.
2 Engine parts: engine ass’y, piston, piston ring, cylinder block, cylinder head, crankshaft, turbocharger, fuel injection pump, starting motor and alternator etc.
3 Undercarriage part: Track roller, Carrier roller, Track Link, Track shoe, Sprocket, Idler and Idler cushion etc.
4 Cab parts: operator’s cab, wiring harness, monitor, controller, seat, door etc.
5 Cooling parts: Radiator, air conditioner, compressor, after cooler etc.
6 Other parts: Service kit, swing circle, engine hood, swing joint, fuel tank, filter, boom, arm, bucket etc.
Packing Details :
inner packing : plastic film for wrapping
external packing : wooden
Shipping :
within 3 days after received the payment , by air or by express or by sea on the basis of the
quantity and emergency circumstances.
1. By Couriers: DHL, UPS, FEDEX, TNT are the main courier companies we are cooperated,
2. By Air: Delivery from the Guangzhou air port to customer's destination city air port.
3. By Sea: Delivery from the Huangpu port .
